GRAYHILL - 71BD30-02-1-AJN - Rotary Switch, 12 Position, 1 Pole, 30 °, 200 mA, 115 V, 71
- No. of Switch Positions: 12 Position
- No. of Poles: 1 Pole
- Angle of Throw: 30°
- Contact Current AC Max: 200mA
- Contact Voltage AC Max: 115V
- Product Range: 71 Series
- Illumination: Non Illuminated
- Contact Current DC Max: 200mA
- Contact Voltage DC Max: 30V
- SVHC: No SVHC (27-Jun-2018)
- Angle: 30°
- Contact Configuration: SPDT
- Contact Current Rating: 4A
- Contact Resistance: 50mohm
- External Diameter: 17.45mm
- Indexing Angle: 30°
- Insulation Resistance: 1000Mohm
- No. of Electrical Operations: 15000
- No. of Wafers per Switch Max: 2
- Resistive Current Rating: 4A
- Shaft Diameter: 0.25"
- Shaft Length: 7.92mm
- Switch Operation: On-Off
- Switching Current AC Max: 500mA
- Switching Current DC Max: 250mA
- Thread Size: 3/8"-32 UNEF-2A
