Description
XP POWER - IH1203S - Isolated Through Hole DC/DC Converter, 1kV Isolation, ITE, 1:1, 2 W, 2 Output, 3.3 V, 200 mA
- No. of Outputs: 2 Output
- Output Power Max: 2W
- Output Voltage - Output 1: 3.3V
- Output Current - Output 1: 200mA
- Output Voltage - Output 2: -3.3V
- Output Current - Output 2: 200mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: IH Series
- Input Voltage DC Min: 10.8V
- Input Voltage DC Max: 13.2V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 7.2mm
- Height: 10.16mm
- Depth: 19.5mm
- SVHC: No SVHC (15-Jan-2018)
