DOLD - IL 5881.12/100 DC 12 - 280V - Voltage Monitoring Relay, Insulation Monitor, IL 5881, DPDT, 3 A, DIN Rail, 230 VAC, Screw
- Product Range: IL 5881 Series
- Contact Configuration: DPDT
- Contact Current: 3A
- Relay Mounting: DIN Rail
- Contact Voltage VAC: 230VAC
- Relay Terminals: Screw
- Contact Voltage VDC: -
- Supply Voltage Max: 415VAC
- Power Consumption: -
- SVHC: No SVHC (15-Jan-2018)
- Adjustment Type: Screwdriver Slot
- Approval Bodies: CE, EN, IEC
- Coil Voltage VAC Nom: 280V
- Contact Current AC Max: 3A
- Contact Current DC Max: 2A
- Contact Voltage AC Max: 230V
- Contact Voltage DC Max: 24V
- Control Voltage Type: DC
- Delay Time Range: 0.5s to 20s
- External Depth: 61mm
- External Length / Height: 35mm
- External Width: 90mm
- Height: 35mm
- Nom Input Voltage: 280VDC
- Operating Temperature Max: 60°C
- Operating Temperature Min: -20°C
- Switch Current Max: 4A
- Switching Current Max: 4A
- Type: 0053805
