COILCRAFT - MSS1278-183MLD - Power Inductor (SMD), 18 µH, 4.5 A, Shielded, 6.1 A, MSS1278, 12.3mm x 12.3mm x 8.05mm
- Inductance: 18µH
- RMS Current (Irms): 4.5A
- Inductor Construction: Shielded
- Saturation Current (Isat): 6.1A
- Product Range: MSS1278 Series
- Power Inductor Case: 12.3mm x 12.3mm x 8.05mm
- DC Resistance Max: 0.0343ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 12MHz
