VISHAY - WKO472MCPEJ0KR - Ceramic Suppression Capacitor, Y5U, 4700 pF, ± 20%, X1 / Y2, 440 V, 300 V, Radial Leaded
- Capacitance: 4700pF
- Product Range: WKO Series
- Capacitance Tolerance: ± 20%
- Suppression Class: X1 / Y2
- Voltage Rating X: 440V
- Voltage Rating Y: 300V
- Operating Temperature Min: -40°C
- Operating Temperature Max: 125°C
- SVHC: No SVHC (15-Jan-2019)
- Approval Category: CSA, NEMKO, SEMKO, SETI, SEV, IMQ, UL, VDE
- Body Diameter: 18mm
- Capacitance Tolerance ±: ± 20%
- Capacitor Application: Safety / Suppression
- Capacitor Terminals: Radial Leaded
- Dielectric Characteristic: Y5U
- External Depth: 5mm
- External Length / Height: 48mm
- External Width: 18mm
- Insulation Resistance: 6000Mohm
- Lead Diameter: 0.8mm
- Lead Length: 30mm
- Lead Spacing: 12.5mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
- Power Factor: 0.025
- Proof Test Voltage Time: 2s
- Proof Voltage: 2500V
- Standard: BS415
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating: 300VAC
- Voltage Rating VAC: 300V
